Humsienk 24V 100Ah LiFePO4 Battery with 100A BMS

$699.99 CAD $599.99 CAD SAVE $100.00 CAD

Hurry! Only Left In Stock.

Quantity: 1 PACK (5.12kWh)

1 PACK (5.12kWh)
2 PACK (10.24kWh)
3 PACK (15.36kWh)
4 PACK (20.48kWh)
Tech Specs
Dimension(in) 19x6.7x9.49 Weight(lbs) 44
Nominal Voltage 25.6V Nominal Capacity 100Ah
Standard/Maximum
Continuous Charging		 20A/100A Max Continues Discharge
Current		 100A
Over-current
Discharge Protection		 300±50A Over-current Charge
Protection		 130±20A
Over-charge Voltage
Protection		 29.2±0.2V Over-charge Voltage
Protection Release		 29.2±0.2V
Over-discharge Voltage
Protection		 18.4±0.24V Over-discharge Voltage
Protection Release		 21.6±0.24V
Short Circuit
Current Protection		 Support Release Condition Cut Load
Charging High
Temperature Protection		 149±41°F Discharge High
Temperature Protection		 158±41°F
High Temperature Protection
Release Condition		 Drop by 50±41°F Charging Low Temperature
Protection		 32±41°F
Discharge Low
Temperature Protection		 -4±41°F Temperature Protection
Release Condition		 Rise by 50±41°F
Cycle Life 6000@DOD80% Self Discharge Rate ≤3%/Month
Series & Paralle Connection Max. 2S4P Case Material ABS+PC/UL94-V0
Battery Pack Certifications IEC62133/RoHS/CE/FCC/UN38.3/Class9 Cell Certifications UL1642/UL2580/UN38.3
